// ❌ Static route configuration — breaks every time a service moves
// In nginx.conf:
// upstream order-service { server 10.0.1.45:3000; }
// When the container restarts, its IP changes. The gateway returns 502.

// ✅ Dynamic routing via Kubernetes service discovery
// Kong declarative config (kong.yaml):
services:
  - name: order-service
    url: http://order-service.default.svc.cluster.local:3000
    # Kubernetes CoreDNS resolves this to the current pod IPs automatically
    # When pods restart, the DNS record updates — gateway never touches a static IP

routes:
  - name: order-routes
    service: order-service
    paths:
      - /api/v1/orders
    strip_path: true
    # Strips /api/v1 prefix before forwarding to the service

// ❌ JWT validation in every service — 7 services, 7 slightly different implementations
// order-service/middleware/auth.ts
import jwt from 'jsonwebtoken'

export function authMiddleware(req: Request, res: Response, next: NextFunction) {
  const token = req.headers.authorization?.replace('Bearer ', '')
  if (!token) return res.status(401).json({ error: 'Missing token' })
  try {
    const decoded = jwt.verify(token, process.env.JWT_SECRET!) // HS256 — shared secret
    req.user = decoded
    next()
  } catch {
    return res.status(401).json({ error: 'Invalid token' })
  }
}
// Problems:
// - JWKS rotation requires restarting all 7 services simultaneously
// - Some services check 'exp', others don't check 'aud' — inconsistent security posture
// - Every service is an availability dependency on the auth server if using token introspection

# Kong JWT plugin — validates at the gateway perimeter, never reaches services
plugins:
  - name: jwt
    config:
      secret_is_base64: false
      claims_to_verify:
        - exp
        - nbf
      key_claim_name: kid
      # Gateway fetches public keys from JWKS endpoint automatically
      # Invalid tokens are rejected with 401 before hitting any service

// ✅ Service receives pre-validated identity via gateway-injected headers
// order-service/middleware/auth.ts — no JWT validation code
export function authMiddleware(req: Request, res: Response, next: NextFunction) {
  const userId = req.headers['x-user-id'] as string
  const roles  = (req.headers['x-roles'] as string)?.split(',') ?? []

  if (!userId) {
    // Gateway should have caught this — but defense in depth: reject if missing
    return res.status(401).json({ error: 'Missing identity headers' })
  }

  req.user = { id: userId, roles }
  next()
}
// Services trust the gateway. The gateway is the single auth enforcement point.
// Rotating the JWT signing key requires updating only the gateway's JWKS cache.

// ❌ In-memory rate limiter — 3 gateway instances = 3× the configured limit
import rateLimit from 'express-rate-limit'

app.use(rateLimit({
  windowMs: 60_000,    // 1 minute
  max: 100,            // 100 requests per minute — per instance
  // With 3 gateway instances behind a load balancer:
  // Client can make 100 requests to instance 1, 100 to instance 2, 100 to instance 3
  // Actual effective limit: 300 requests/minute — 3× the intended limit
}))

// ✅ Distributed rate limiter — accurate across all gateway replicas
import { RateLimiterRedis } from 'rate-limiter-flexible'
import { createClient } from 'redis'

const redis = createClient({ url: process.env.REDIS_URL })
await redis.connect()

const rateLimiter = new RateLimiterRedis({
  storeClient: redis,
  keyPrefix: 'rl:gateway',
  points: 100,          // 100 requests
  duration: 60,         // per 60 seconds
  blockDuration: 60,    // block for 60s after limit exceeded
})

export async function rateLimitMiddleware(req: Request, res: Response, next: NextFunction) {
  const key = req.headers['x-user-id'] ?? req.ip   // Per-user or per-IP
  try {
    const result = await rateLimiter.consume(key)
    res.setHeader('X-RateLimit-Remaining', result.remainingPoints)
    res.setHeader('X-RateLimit-Reset', new Date(Date.now() + result.msBeforeNext).toISOString())
    next()
  } catch (rejRes) {
    res.setHeader('Retry-After', Math.round(rejRes.msBeforeNext / 1000))
    res.setHeader('X-RateLimit-Remaining', 0)
    res.status(429).json({
      type: 'https://api.example.com/problems/rate-limit-exceeded',
      title: 'Rate Limit Exceeded',
      status: 429,
      detail: `Rate limit of 100 requests/minute exceeded. Retry after ${Math.round(rejRes.msBeforeNext / 1000)}s.`,
    })
  }
}
// All 3 gateway instances share the same Redis counter.
// The limit is accurate regardless of which instance the load balancer routes to.

// ✅ Gateway-level circuit breaker — protects all downstream services uniformly
import CircuitBreaker from 'opossum'

// Per-service circuit breaker at the gateway level
const circuitBreakers = new Map<string, CircuitBreaker>()

function getBreaker(serviceName: string) {
  if (!circuitBreakers.has(serviceName)) {
    const breaker = new CircuitBreaker(
      (req: ProxyRequest) => forwardToService(serviceName, req),
      {
        timeout: 5000,
        errorThresholdPercentage: 50,
        resetTimeout: 30_000,
        volumeThreshold: 10,
      }
    )
    breaker.fallback(() => ({ status: 503, body: {
      type: 'https://api.example.com/problems/service-unavailable',
      title: 'Service Temporarily Unavailable',
      status: 503,
      detail: `${serviceName} is temporarily degraded. Please retry in 30 seconds.`,
    }}))
    circuitBreakers.set(serviceName, breaker)
  }
  return circuitBreakers.get(serviceName)!
}

// ✅ External REST clients → gateway translates → internal gRPC services
// The public API remains REST/JSON; the internal service is gRPC-native

import * as grpc from '@grpc/grpc-js'
import * as protoLoader from '@grpc/proto-loader'

const packageDef = protoLoader.loadSync('order.proto')
const orderProto = grpc.loadPackageDefinition(packageDef).order as any
const orderClient = new orderProto.OrderService(
  'order-service:50051',
  grpc.credentials.createInsecure()
)

// Express REST endpoint on the gateway — translates to gRPC upstream
app.get('/api/v1/orders/:id', async (req, res) => {
  orderClient.getOrder({ orderId: req.params.id }, (err: any, response: any) => {
    if (err) {
      if (err.code === grpc.status.NOT_FOUND) return res.status(404).json({
        type: 'https://api.example.com/problems/not-found',
        title: 'Order Not Found',
        status: 404,
        instance: `/orders/${req.params.id}`,
      })
      return res.status(502).json({ type: 'https://api.example.com/problems/upstream-error', status: 502 })
    }
    res.json(response) // gRPC Protobuf response serialized to JSON for the REST client
  })
})

// ✅ Gateway generates the root trace span — all downstream services inherit it
import { NodeSDK } from '@opentelemetry/sdk-node'
import { OTLPTraceExporter } from '@opentelemetry/exporter-trace-otlp-http'
import { ExpressInstrumentation } from '@opentelemetry/instrumentation-express'
import { HttpInstrumentation } from '@opentelemetry/instrumentation-http'
import { context, trace, propagation } from '@opentelemetry/api'
import { W3CTraceContextPropagator } from '@opentelemetry/core'

const sdk = new NodeSDK({
  traceExporter: new OTLPTraceExporter({ url: process.env.OTEL_EXPORTER_OTLP_ENDPOINT }),
  instrumentations: [new HttpInstrumentation(), new ExpressInstrumentation()],
  serviceName: 'api-gateway',
})
sdk.start()

// Gateway middleware: inject traceparent header before forwarding
app.use((req, res, next) => {
  const span = trace.getActiveSpan()
  if (span) {
    const carrier: Record<string, string> = {}
    propagation.inject(context.active(), carrier)
    // carrier now contains: { 'traceparent': '00-{traceId}-{spanId}-01' }
    // Forward all trace context headers to upstream services
    Object.entries(carrier).forEach(([key, val]) => req.headers[key] = val)
  }
  next()
})

// ✅ Gateway aggregates: one client request → multiple upstream calls → one response
// Reduces network round trips from 4 to 1 for a product detail page

app.get('/api/v1/product-details/:id', async (req, res) => {
  const { id } = req.params
  const userId = req.headers['x-user-id'] as string

  // Fan out in parallel — all 4 calls run concurrently
  const [product, inventory, pricing, wishlist] = await Promise.allSettled([
    productClient.getProduct({ id }),
    inventoryClient.getStock({ sku: id }),
    pricingClient.getPrice({ sku: id, userId }),
    wishlistClient.checkWishlist({ sku: id, userId }),
  ])

  res.json({
    product: product.status === 'fulfilled' ? product.value : null,
    inventory: inventory.status === 'fulfilled' ? inventory.value : { available: null },
    pricing: pricing.status === 'fulfilled' ? pricing.value : null,
    inWishlist: wishlist.status === 'fulfilled' ? wishlist.value.inList : false,
    // Partial failures are surfaced as null — client degrades gracefully
  })
})
// Total latency = max(4 parallel calls), not sum(4 sequential calls)
